Power Consumption:600 W
Power Amplifier Protection:DDT™ speaker protectionwith defeat switchShort Circuit protectionThermal protection circuitCooling fan failure protection circuitCurrent limit protection circuitDC output protection circuitMinimum Load: 4 ΩInput Sensitivity: 600 mVRMS
Output Jacks:Two 1/4" Speakon® combinationjacks in parallel
Power Output:300 w, 48.9 VRMS/8 Ω450 w, 42.4 VRMS/4 Ω
Noise:> 100 dB below full power @ 8 Ωtypically -105 dBPreamplifier SpecificationsSettings (unless otherwise stated):
Pre gain: 4 (12 o'clock)Bright: OutMute: outContour: 0 (fully counterclockwise)Low: 0High: 0Low Cut: OutGraphic EQ: All sliders set to centerEQ Bypass: OutPost Gain: 10 (fully clockwise)Octaver: MIN(fully counterclockwise)Octaver Defeat: OutDDT™: ActiveInput Sensitivity (High Gain): Nominal Input: 616 mVRMSMinimum Input: 34.1 mVRMSMaximum Input: 2.3 VRMS(maximum signal at input before clipping)Input Sensitivity (Low Gain): Nominal Input: 1.0 VRMSMinimum Input: 59.3 m VRMSMaximum Input: 7.2 VRMS(maximum signal at input before clipping)Tuner Send: Buffered from input jack with no equalizationD.I. XLR Output: Buffered from input jack with no equalizationFailsafe D.I. Backup: 48 v phantom powerWeight: 21.8 lb.
