C23-031056
Instrument: Custom ''000/OM'' Auditorium Body
Orientation: Right Handed
Neck Joint: Dovetail
Appointment Level: Standard
Adhesive: Modern Adhesive
Top Material: Adirondack Spruce
Bracing Material, Top: Adirondack Spruce
Back and Side Material: Guatemalan Rosewood
Binding Material: European Flamed Maple
Top Pearl: None
Rosette Style: Style 28 Black Maple Fiber
Bridge Style: Modern Belly
Neck Material: 12/4 Genuine Mahogany
Neck Profile: Modified Low Oval
Neck Taper: High Performance Taper
Tuning Machines: Grover Gold V97-18GA StaTite 18:1
Vintage Btn
Fingerboard Material: Black Ebony
Fingerboard Inlay: Foden Style
Finish Type: Standard
Finish Package: Gloss Body w/ Satin Neck
Top Color: Aging Toner
Frets Clear: 14 Frets Clear of Body
Body Shape: ''000/OM'' Auditorium Body
Inspired by: 000 - 28 Style
Appointment Level: Standard
Base Model Note: NAMM 2023 - Guatemalan RW - Set # 25
Adhesive: Modern Adhesive
Orientation: Right Handed
Body Depth: Standard
Scale Length: 24.9"
Compensated Scale Length: 24.980"
Neck Joint: Dovetail
Truss Rod: Adjustable 14 Fret
Construction Note:
TOP
Top Material: Adirondack Spruce
Top Material Upgrade: Standard
Final Top Grade: Grade 3-4
Top Thickness: Standard
Bracing Material, Top: Adirondack Spruce
Bracing Pattern, Top: X Brace
Bracing Pattern Number, Top: 19-A 000
Bracing Shape, Top: Scalloped
Bracing Style, Top: Golden Era
Bracing Size, Top: 5/16''
Top Note:
Binding Material: European Flamed Maple
Rosette Style: Style 28 Black Maple Fiber
Pickguard Material: Faux Tortoise
Pickguard Pattern: Pattern 3B
Rosette and Pickguard Note: Style 28 Marquis Rosette by Request
BACK AND SIDE
Front Block: BL,Mahogany,Front,000,14,Adj
Rear Block: BL,Mahogany,Rear,000
Back Piece Qty: 2 Piece
Back and Sides Material: Guatemalan Rosewood
Back and Sides Material Upgrade: Premium
Wedge Final Grade:
Back Purfling: Style 28 (Checker)
Bracing Material, Back and Sides: Spruce
Bracing Pattern: 00014 Fret
Center Strip: Spruce
Center Strip Stamp Location: Between 1st & 2nd Brace
Ribbons: Spanish Cedar
Endpiece Material: European Flamed Maple
NECK
Neck Material: 12/4 Genuine Mahogany
Neck Profile: Modified Low Oval
Neck Taper: High Performance Taper
Heelcap Material: European Flamed Maple
Headstock: Solid
Diamond Volute: Standard
Headstock Taper: Square
Corners: Standard
Headplate Material: East Indian Rosewood
Headplate Material Grade: Standard
Headplate Thickness: Standard
Headplate Decal: Old Style Gold
Stamp: C.F. Martin & Co.
Neck Material, Shape, Headstock Note:
FINGERBOARD
Fingerboard Material: Black Ebony
Fingerboard Material Grade: 3
Fingerboard Oil: Yes
Fingerboard Radius: 16''
Fingerboard Width at Nut: 1 3/4"
Fingerboard Width at 12th Fret: 2 1/8"
String Spacing: 2 5/32''
Fingerboard Length: 17.524''
Fingerboard Thickness: Standard Thickness
Fret Wire: Standard
Fret Slot: 0.023 Pocketed
Total Frets: 20 Total
Fingerboard Inlay: Foden Style
Fingerboard Inlay Pearl Species: Select Abalone
Side Dots: White
Side Dot Postion: One at 3rd, 5th, 7th, 9th, Two at 12th, One at 15th & 17th Frets
Nut Material: Bone
Nut Positioning: Flat
Fingerboard Note:
FINISH
Finish Type: Standard
Finish Package: Gloss Body w/ Satin Neck
Satin Finish Package: Not Applicable
Finish Taping Notes: Tape Rosette & Inlays
Notes for Finish: ICA Sealer on Back, Sides /Tape Heelcap for Stain and fill
Top Color: Aging Toner
Body Filler: Rosewood
Neck Filler: Rosewood
Neck Stain: Mahogany
Finish and Extras Note:
BRIDGE
Bridge Material: Black Ebony
Bridge Style: Modern Belly
Saddle Style: Drop in Saddle
Saddle Material: Compensated Bone
Bridge Pins: White w/ Faux Tortoise
Bridge End Pins: White w/ Faux Tortoise
Bridge Note:
EXTRAS
Tuning Machines: Grover Gold V97-18GA StaTite 18:1 Vintage Btn
Tuning Machine Drilling: R 11/32''
Strings: Authentic Acoustic Lifespan 2.0
Strings Guage: Light
Case: Molded Hardshell
Custom Shop Credentials Book: Yes
