Input / Output
Speaker Input
Jack 6.35mm (1/4”) unbalanced (TS, Tip/Sleeve)
Maximum input Voltage: 140V AC (45dBu)
Max Security Load: 270Ω / 20W
Load Input Level
Adjustable via potentiometer with continuous attenuation (-inf) to continuous amplification (+20dB)
Speaker Outputs
(2) Jack 6.35 mm (1/4”) unbalanced (TS)
Min Load: 3.5Ω
Max Output Power (single channel at THD+N <1%):
1x 215 W RMS @ 4Ω
1x 120 W RMS @ 8Ω
1x 50W RMS @ 16Ω
Maximum Output Power (both channels driven at THD+N <1%):
2x 150 W RMS @ 4Ω
2x 120 W RMS @ 8Ω
2x 50W RMS@ 16Ω
Level output adjustable for fine channel symmetry
Line Inputs
Dual-Mono, (2) Jack 6.35mm (1/4”) balanced (TRS, Tip/Ring/Sleeve)
Switched jacks for routing to an unplugged channel
Impedance: 300Ω
Gain (In to Out): +4 to -inf dB
Maximum Output Level: 20dBu
Noise: Under -99dBu from 20Hz to 20kHz
Frequency Response @ -1dB: 20Hz to 20kHz
FX Loop
Dual-Mono Fx loop with independent CHANNEL A and CHANNELB controls
(2) SEND + (2) RETURN via 6.35mm (1/4”) unbalanced (TS) Jack
Compatibility with +4dBu and -10dBV devices, selectable via a dedicated switch per channel
DRY/WET potentiometer with ON/OFF switch
Facilities to Copy CHANNEL A return to CHANNEL B output via dedicated switch
FX loop activation/deactivation via Footswitch with a 6.35mm (1/4”) Jack; (TRS, Tip/Ring/Sleeve) or (TS, Tip/Sleeve) compatible and configurable via a dedicated Footswitch behaviour switch
Load Box
Reactive Load featuring a Celestion Approved Load Response with nominal impedance: 4- or 8- or 16-Ohms (switchable)
Maximum Admissible Power
200W RMS (assuming proper ventilation)
Maximum Temporary Admissible Power
250W peak (assuming proper ventilation)
Tone Shaping
Tone Control
(1) DEPTH and (1) PRESENCE control per CHANNEL
Flat response on potentiometers at 0%
(1) MOJO control per CHANNEL to deliver high-power feel at low volume
Depth: +8dB @75Hz on potentiometer at 100%
Presence: +8dB @4kHz on potentiometer at 100%
Safety / Protection
Cooling
Passive cooling with amplifier heatsink and Load Box heatsink
Active cooling with temperature-controlled fan with 2 speeds (Slow & Boost)
Thermal Security
To prevent damage to the internal Load Box, thermal cut off is implemented when the internal temperature rises over a predesignated threshold. When active, a 270Ω security load is placed into
ffect and the signal is muted
Power
Power Supply
Type: IEC60320 C14 power connector
Input Voltage: Compatible with 100V – 230V @ 50- to 60Hz
Power: 100W Max
Dimensions & weight
Width x Depth x Height*:
365mm x 89mm x 220mm
365mm x 89mm x 240mm Including connectors and knobs
Weight:
6.9kg
