IR-LOADER
To utilize IR-X’s IR technology independently of the preamp section, just plug your preferred preamp or pedals into its effects loop return. It’s a great way to harness all of its power amp and speaker simulation onstage or in the studio.
FEATURES
All-tube HIGH-VOLTAGE preamp – DI
2 x 12AX7 preamp tubes
Two independent channels + boost
Channel 1 (Top channel) clean to gritty
Channel 2 (Bottom channel) high gain drive
MIDI programmable features:
Channel select / Boost
IR select
Thump and Presence – three-way switch per channel
Effects loop ON/OFF
Boost Lock
Power amp simulation with software editable Presence and Thump (per channel)
Low latency Impulse Response cabinet simulation (bypassable)
Three position CAB/IR select switch per channel (programmable via software)
12 free Friedman IRs or load your own
Boost Volume and Gain controls (per channel)
Volume and Gain controls (per channel)
Full EQ consisting of Bass, Middle, Treble (per channel)
3-way Bright switch (Channel 1)
2-way Tight switch (Channel 2)
Three multi-function foot switches
Ultra-transparent series FX loop (bypassable)
TRS balanced output
Headphone output
MIDI 5 pin standard connector and USB MIDI
USB software editor – powered by SYNERGY
Limited 3-year Warranty
Universal 12V Power Supply Included
6 Foot USB2.0 A Male to B Male cable Included
Dimensions (Including Knobs): 5.5” (D) x 6.5” (W) x 2.3 (H)
Weight: 1.5 lbs.
