IRONMAN II REACTIVE ATTENUATION.
The Ironman II reactive power attenuator gives Tone King amplifiers increased flexibility for any gig, session, or rehearsal. And thanks to its reactive load technology and HF Compensation,
it does it while always maintaining your cranked amp tone and feel. Go ahead, crank your amp to the sweet spot then reign in the volume for thick, rich tone at usable levels.
KEY FEATURES:
Footswitchable 2-channel design (rhythm, lead)
Ironman II reactive attenuation
Bias modulation tremolo circuit delivers vintage-style pulse
Tube driven spring reverb with wide-ranging control
Custom-voiced 12” Eminence speaker
TECHNICAL DETAILS
Configuration:
20W, 1×12 Two Channel Combo
Assembled in the USA using premium worldwide components
Speaker:
Custom designed 12″, 8-Ohm, Ceramic Magnet speaker made by Eminence
Preamp:
2-Channel (Rhythm, Lead), Footswitchable
Rhythm Channel controls: Volume, Treble, Bass
Lead Channel controls: Volume, Tone
Reverb:
Tube Driven spring reverb
Full size 2-spring reverb pan
Tremolo:
Bias modulation type tremolo circuit
Footswitch controllable
Rhythm Channel:
Vol, Treb, Bass
Lead Channel:
Vol, Tone, Mid-Bite
Output Power: 20W
Speakers:
12”, 8-Ohm Ceramic Magnet ‘Tone King 33’ Made by Eminence
Built-In Ironman II Compensated Power Attenuator:
Controls:
Attenuation Level, HF Compensation, Rhythm Channel Bypass Enable
Attenuation Steps: 0db, -3db, -9db, -15db, -24db, -36db
HF Compensation: tailors the high frequency “presence” as desired
Rhythm Channel Bypass: when selected, the attenuator will automatically be bypassed when the rhythm channel is selected
Footswitch:
Two button footswitch (channel, tremolo)
LED status indicators
Tubes: 4x12AX7A, 1x12AT7, 2x6V6GT, 1x5AR4
Output Stage: 2x6V6, cathode biased, no negative feedback
Output Power: 20W RMS
Speaker Impedence: 8 Ohms
Ironman II Attenuator design features: Precision Tuned Reactive Load
Fletcher-Munson Volume Compensation Circuitry
Damping factor correction
